ID

OSMP1708

Date

20 August 2024

Source

Reported Location

Year

Munition Category

Functional use

Tentative Model

Base Colour

Marking Colour

Condition

Guidance

Domain

Calibre

Analyst Note

This image shows a Hydra-70 rocket fitted with an Advanced Precision Kill Weapon System (APKWS) guidance kit, converting it into a guided missile. In this case, the missile features an M151 high explosive (HE) warhead fitted with either an M427 or M423 point-detonating (PD) fuze. The rocket motor model cannot be determined from this source alone, but it is most likely to be a MK 66-series motor. The launcher appears to be a LAND-LGR4 model produced by Arnold Defense. (ARES)
