OSMP2271
Mine Submunition Ukraine PTM-3
Analyst Note:
This image shows a PTM-3 scatterable anti-vehicle mine, surrounded by the remnants of an unmanned aerial vehicle (UAV). Russia has been dispensing PTM-3 mines from one-way attack UAVs as they fly towards their primary target. Typically, these OWA UAVs are fitted with KPTM-3 remote mining canisters mounted under the wings, which eject their PTM-3 payload midair. The PTM-3’s fuze features an arming delay which is sufficient to allow the mine to fall to the ground before fully activating. (ARES)
OSMP2217
Submunition Iran [TEMP] ARES-TMID-0012
Analyst Note:
This image shows an Iranian ballistic missile’s ‘manoeuvrable re-entry vehicle’ (MaRV; a detachable, steerable payload section) at the IRGC Aerospace Museum in Tehran, with what appear to be inert models of the submunitions Iran has deployed against Israel in the recent conflict. ARES has assigned a temporary identification of TMID-0012 to these submunitions. (ARES)
OSMP2284
Mine Submunition Ukraine ADAM / M67 / M72
Analyst Note:
This image shows a U.S. Area Denial Artillery Munition (ADAM), an anti-personnel scatterable landmine which is dispensed from the rear of M692 and M731 155 mm artillery gun projectiles. Each projectile contains 36 ADAM submunitions. The submunition can deploy up to seven tripwires out to 20 ft (6.1 m). Any movement of a tripwire or movement of the ADAM body will result in a small kill mechanism being ejected to a height of a 6–8 ft (1.8 m–2.4 m) prior to detonating. Each munition contains a small amount of depleted uranium. The ADAM was previously designated as either the M67 or M72, with the only difference being the self-destruct time delay. (ARES)
OSMP2283
Mine Submunition Ukraine DM1399
Analyst Note:
The German DM 1399 (AT2) anti-tank landmine shown here can be dispensed from rockets and ground vehicles. Upon being dispensed, a small parachute is deployed in order to slow the mine’s descent and assist in in landing base down; the parachute is released upon impact by an impact-release connector. Upon impact, from five to 12 (six shown) spring-loaded, metal legs deploy to right the mine; arming is completed anywhere from 15 seconds to five minutes thereafter. The base of the cylindrical body houses the battery and electronics assembly, with the main explosive charge and Misnay–Schardin shaped charge plate immediately above. The body is topped by a dome cover and an S3 sensor wire which extends approximately 600 mm (12 in) above the body of the mine. (ARES)
OSMP2282
Mine Submunition Ukraine DM1399
Analyst Note:
Shown is a German DM 1399 (AT2) dispensed, anti-tank landmine which is high explosive with a Misznay-Schardin charge to penetrate the bottom of armored vehicles. The DM 1399 reportedly has magnetic and contact fuzing (model S3 fuze), along with an anti-disturbance feature to interfere with clearance operations and a self-destruct time delay of up to four days. The mines are dispensed from rockets (MLRS). Currently the mines are in use by Finland, German, Norway, United Kingdom and Ukraine (donated by Germany and Norway). Italy is a former user which destroyed their ~45,000 mine stockpile in 1997 as part of the Ottawa Treaty, due to the mine’s anti-disturbance feature which can be activated by personnel and not just vehicles. (ARES)
OSMP2211
Submunition Iran [TEMP] ARES-TMID-0012
Analyst Note:
This image shows the ‘manoeuvrable re-entry vehicle’ (MaRV; a detachable, steerable payload section) of an Iranian ballistic missile loaded with submunitions. It appears there are three different models of submunition loaded into the MaRV (black, blue, and red). The black and blue submunitions are most likely anti-personnel designs, whilst the red submunitions (indicated by a red box) are likely designed with penetrating or shaped-charge warheads to target vehicles or structures. Some submunitions may utilise time-delay fuzing, allowing for random detonations over several hours or days to hamper clearance efforts, denying use of the afflicted area. Reports have shown Iran has used ballistic missiles with mixed submunition loads, and suggest that this type of warhead can scatter its payload up to a radius of 8 km. (ARES)
OSMP2302
Mine Submunition Iran BLU-91/B
Analyst Note:
The BLU-91/B pictured here is an aerially dispensed anti-vehicle scatterable landmine that uses a magnetic-influence fuze to function a shaped charge relying on the Misnay–Schardin Effect. The munition is fitted with three self-destruct delay settings. The aeroballistic adaptor is commonly broken off upon impact and the remnants of the adhesive holding it in place can be seen (yellow). One side of the munition has a bore-riding pin which is held in place while in the dispenser. Once dispensed, the bore riding pin is released and starts the arming process. The BLU-91/B is 121 mm (4.75 in) in diameter and 56 mm (2.6 in) in height. (ARES)
OSMP2276
Mine Submunition Ukraine POM-2
Analyst Note:
Highlighted is a Russian POM-2 scatterable, high explosive, anti-personnel submunition which deploys six legs for stabilization upon impact and four pressure- and pull-sensitive 9.5m (31.17’) long tripwires which end in a ‘Y’ fashion with plastic weights. Upon deployment, nylon ribbons (seen in the foreground) are deployed to help ensure the submunition lands upright, in addition to the stabilizing legs. Originally designed to be dispensed by rockets and helicopters, the war in Ukraine has seen the POM-2 modified for deployment via drone, hand and even from RPGs. (ARES)
OSMP2275
Mine Submunition Ukraine PFM-1 series
Analyst Note:
Pictured is a Russian PFM-1 or PFM-1S submunition which are small plastic (low density polythene), liquid high explosive, anti-personnel scatterable landmines with a pressure fuze and may be green, white, sand or brown (shown) in color. The only difference between the models is that the PFM-1S incorporates a nominal self-destruct of 40 hours, though they may remain active for far longer and are known to randomly self-destruct for weeks after deployment. They weigh approximately 70 grams (2.47 oz.) and are typically dispensed from cannisters, but the war in Ukraine has seen them dispensed from drones as well. (ARES)
OSMP2232
Mine Submunition Iran BLU-91/B
Analyst Note:
A BLU-91/B GATOR anti-vehicle landmine is seen in this image, with the remains of an aeroballistic adaptor visible. BLU-91/B mines can be deployed from cluster bombs or from vehicle-mounted dispensers, however the presence of the square aeroballistic adaptor here indicates that this example was deployed from an air-delivered cluster bomb. (ARES)
10 March 2026

AP highlights images of Iranian submunitions

OSMP2037
Submunition Israel [TEMP] ARES-TMID-0012
Analyst Note:
This image shows an unexploded Iranian submunition of unknown designation. Visually similar examples have been documented following Iranian ballistic missile strikes on Israel in June 2025 and March 2026. At least two variants are believed to exist, but publicly available details remain limited at time of review. (ARES)
