1–22 of 22
OSMP1666
Rocket or Missile Russia GMLRS
Analyst Note 28 November 2025
This munition remnant is marked with a manufacturer’s CAGE Code (“MFR-05DN8”) which indicates it was produced by Klune Industries. Klune Industries is a sub-contractor on the GMLRS contract. (ARES)
OSMP1667
Rocket or Missile Russia GMLRS
Analyst Note 21 November 2025
This munition remnant is marked with a manufacturer’s CAGE Code (“MFR-62313”) which indicates it was produced by Lockheed Martin. Lockheed Martin is the primary contractor that makes GMLRS missiles. (ARES)
OSMP1668
Rocket or Missile Russia GMLRS › M30
Analyst Note 28 November 2025
This image shows a remnant from an American M30 Guided Multiple Launch Rocket System(GMLRS) missile, which carries M77/M101 submunitions. The yellow diamond markings indicate a payload of explosive submunitions. (ARES)
OSMP1671
Rocket or Missile Russia GMLRS
Analyst Note 28 November 2025
This munition remnant is marked with a manufacturer’s CAGE Code (“MFR-57413”) which indicates it was produced by the Maine Machine Products Company, a sub-contractor on the GMLRS contract. (ARES)
OSMP1655
Rocket or Missile Ukraine GMLRS
Analyst Note 29 September 2025
This munition remnant is marked with a manufacturer’s CAGE Code (“MFR CAGE CODE: 62313”) which indicates it was produced by Lockheed Martin. Lockheed Martin is the primary contractor that makes GMLRS missiles. (ARES)
OSMP1660
Rocket or Missile Ukraine GMLRS
Analyst Note 29 September 2025
This remnant shows a munition component marked with the CAGE Code for a sub-contractor who produced part of a larger munition. “64344” is the code for Unique Electronics Inc., a known sub-contractor working on Lockheed Martin’s GMLRS contract. One of the parts they make is the “CABLE ASSEMBLY W459“, as seen in this image. (ARES)
