RGM/UGM-109 Tomahawk Land Attack Missile (TLAM) series
An American-designed series of surface-to-surface cruise missiles primarily produced by Raytheon since 1997 and launched from surface ships and submarines. With a maximum effective range of around 2,500 km depending on the variant, the Tomahawk can be fitted with a number of warhead types, including unitary high explosive (blast) and blast-fragmentation, as well as submunitions. Guidance is provided by GPS and inertial navigation alongside Terrain Contour Matching (TERCOM) and Digital Scene Matching Area Correlation (DSMAC) functions. It has seen use in a variety of conflicts including the 1991 Gulf War, 2003 Iraq War, the Libyan and Syrian Civil Wars, and in recent strikes targeting the Houthis in Yemen.

Collection

US munitions used in Yemen 2025

Verified images of U.S. munitions during the Trump administration’s bombing campaign against the Iranian-backed Houthi militant and political group.

View this collection →
OSMP1248
Rocket or Missile Yemen RGM/UGM-109 Tomahawk Land Attack Missile (TLAM) series
Analyst Note:
This image shows a fragment of a RGM/UGM-109 Tomahawk Land Attack Missile (TLAM) series missile's WDU-36/B warhead. The WDU-36/B warhead is a penetrator warhead for the TLAM, and is one of several available warhead options for TLAM series missiles. The complete "WDU" designation isn't visible, but the part number (3123AS921) is associated with the WDU-36/B. (ARES)
OSMP1196
Rocket or Missile Philippine Sea RGM/UGM-109 Tomahawk Land Attack Missile (TLAM) series
Analyst Note:
This image shows an RGM-109-series Tomahawk Land Attack Missile (TLAM) being launched from the USS Curtis Wilbur (DDG 54), a Arleigh Burke-class guided missile destroyer. The RGM/UGM-109 TLAM series are surface-to-surface missiles. The ‘R’ and ‘U’ in RGM and UGM, respectively, denote the intended launch platform, with ‘R’ denoting surface platforms, such as ships, and ‘U’ denoting subsurface platforms, such as submarines. (ARES)
